Trailer maintenance is not glamorous, but it is where small problems become big ones if ignored. A well-maintained trailer keeps you legal, safe, and profitable. This guide covers the essentials: what to check, how often, and what it costs. You can start with a simple walk-around today and build a routine that prevents breakdowns and DOT violations.

Why Trailer Maintenance Matters

Your trailer takes the same abuse as your truck, but it gets less attention. A failed brake or a blown tire can cost you thousands in repairs, downtime, and fines. According to the FMCSA, brake violations are among the top out-of-service criteria. Regular maintenance is not optional; it is a business expense that pays off. A basic inspection routine takes 30 minutes and can catch issues before they strand you on the shoulder.

The 30-Minute Walk-Around: What to Check Weekly

Do this every week, or before every long trip if you run irregularly. Use a flashlight and a tire gauge. Look for:

• Tires: Check pressure when cold. Proper pressure is usually 100-110 psi for trailer tires, but confirm the sidewall rating. Look for cuts, bulges, or uneven wear. Use a tread depth gauge; replace at 4/32 inch for steer, 2/32 for drive and trailer, but many fleets replace at 4/32 for all positions.
• Brakes: Check air pressure builds to 100-120 psi. Listen for air leaks. Inspect brake chambers for rust or damage. Look at the slack adjuster: it should not have excessive travel. If you have drum brakes, check for oil or grease on the lining.
• Lights and reflectors: Test all lights: turn signals, brake, clearance, and marker. Replace burned bulbs immediately. Clean reflectors; they are cheap and critical for visibility.
• Coupling and landing gear: Check the kingpin for wear and the fifth wheel plate for lubrication. Lower the landing gear and inspect the legs for cracks. Ensure the crank handle is secure.
• Suspension and frame: Look for cracks, loose U-bolts, or missing hardware. Check the air bags (if equipped) for leaks and proper inflation.
• Doors and seals: Open and close all doors. Check the rubber seals for tears. A bad seal lets in water, which ruins cargo and causes rust.

Brake Maintenance: The Most Critical System

Brakes are your number one safety system. Federal law requires brakes on all axles, and they must work within specific limits. Here is what to do:

• Check brake adjustment every week. Use a ruler or a brake stroke indicator. The pushrod travel should be within the range marked on the chamber (usually 1.5 to 2 inches for a standard type 30 chamber). If it exceeds that, have it adjusted.
• Inspect brake linings every 30,000 miles or 6 months, whichever comes first. Replace linings when they are worn to 1/4 inch or less. Cost: $300-$600 per axle for parts and labor, depending on whether you do it yourself.
• Check brake drums for heat cracks, scoring, or out-of-round. A drum can be turned once, but if it is too thin, replace it. New drums run $100-$200 each.
• Test the emergency brake by releasing the trailer brakes and pulling the red knob. The trailer should stop within a reasonable distance.

Tire Care: Extend Life and Avoid Blowouts

Tires are the most common cause of roadside breakdowns. Proper maintenance can double their life.

• Check pressure weekly, not just visually. Use a calibrated gauge. Underinflation by 10 psi can reduce tread life by 10% and increase fuel consumption.
• Inspect for damage after every trip. Look for sidewall cuts, bulges, or nails. Remove stones from treads.
• Rotate tires every 20,000-25,000 miles. This evens out wear, especially on trailers that are loaded unevenly.
• Replace tires when tread depth is below 2/32 inch, or if there is any belt separation. A new trailer tire costs $200-$400 each. Consider retreads for trailers; they are common and safe if done by a reputable shop.

Wheel Bearings and Hubs: The Silent Killer

Bearing failure can cause a wheel to seize, which is dangerous and expensive. Here is the routine:

• Check for heat after a long drive. Touch the hub (carefully) or use an infrared thermometer. If one hub is significantly hotter than others, the bearing is failing.
• Repack bearings every 12 months or 100,000 miles. This involves removing the hub, cleaning the old grease, and packing new grease. Cost: $150-$300 per axle if done by a shop.
• Inspect seals for leaks. Grease on the inside of the tire or on the drum is a sign of a bad seal.

Electrical and Lighting: Keep It Legal

DOT requires all lights to work. A burned-out marker light is a ticket magnet.

• Check the 7-way plug for corrosion or bent pins. Clean with electrical contact cleaner.
• Test all lights with a helper or a tester. Replace bulbs as needed. LED lights last longer but cost more upfront.
• Check the wiring for chafing or exposed wires, especially near the frame and under the trailer.

Trailer Frame and Body: Rust and Corrosion

Rust is not just ugly; it weakens the structure. Address it early.

• Inspect the frame for rust, especially around welds and crossmembers. Use a hammer to tap for weak spots. If you find flaking rust, scrape and treat it with a rust converter.
• Check the floor for rot or damage. A soft spot can lead to cargo falling through.
• Seal any cracks in the roof or walls. Use a quality sealant designed for trailers.

Seasonal and Annual Maintenance Schedule

Here is a simple schedule to keep you on track:

Task	Frequency	Cost Range
Walk-around inspection	Weekly	$0
Tire pressure check	Weekly	$0
Brake adjustment check	Weekly	$0
Brake lining inspection	Every 6 months or 30k miles	$0 if DIY, $100-$300 for shop
Wheel bearing repack	Annually or 100k miles	$150-$300 per axle
Full DOT inspection	Annually	$100-$200
Frame rust treatment	As needed	$50-$200 in materials

FAQ

How often should I grease the trailer’s moving parts?

Grease the fifth wheel plate, landing gear, and door hinges every month or every 10,000 miles. Use a lithium-based grease. Over-greasing can attract dirt, so wipe off excess.

Can I do trailer maintenance myself, or should I hire a shop?

You can do basic checks and tire pressure yourself. Brake work and bearing repacks require tools and experience. If you are not comfortable, hire a certified mechanic. It is cheaper than a breakdown.

What is the most common DOT violation on trailers?

Brake-related violations, followed by lighting and tire issues. Keeping a log of your inspections can help you prove due diligence.

How do I know if my trailer brakes are out of adjustment?

Listen for a grinding sound when braking, or check the pushrod travel. If it exceeds the limit, have them adjusted. Some trailers have automatic slack adjusters, but they still need manual checks.

The Bottom Line

Trailer maintenance is a non-negotiable part of your business. A weekly 30-minute inspection, a monthly grease job, and an annual professional check will keep you safe and legal. The cost of maintenance is a fraction of the cost of a breakdown, a fine, or an accident. Start today: do a walk-around, check your tire pressures, and look at your brakes. Your trailer will thank you, and so will your bottom line.
